Next Phase of Underpass Construction Complete on SR 86!


Another phase of construction is complete on the first two wildlife underpasses on State Route 86 (SR 86)! On February 27th and 28th 2014, the second set of pre-cast arches were put in place to complete the structures! Initial installation of the arches began late November 2013, and in the coming months, the space on the sides of the arches will be back-filled with a mixture of dirt and concrete slurry for stabilization. This will be followed by continued paving of the new, widened roadway. Cameras will then be installed to monitor and document wildlife use of the underpass in the years ahead. Wildlife fencing linking the passage structure sites will be put in place in the coming years totaling 44, 677 lineal feet on both sides of SR 86. The total cost of both underpass constructions is estimated at $746, 280.

The last arch being fixed in place on the Kitt Peak segment. There are 15 total arches.

The last arch being fixed in place on the Kitt Peak segment. There are 15 total arches, making the underpass 90 feet long.

SR 86 links Tucson to the Tohono O’odham Nation and lies within a critical corridor for wildlife movement. These underpasses were funded by the Regional Transportation Authority and incorporated into an ADOT widening project on the Kitt Peak segment (milepost 132-137) and Santa Rosa segment (milepost 128-132) of SR 86. Milepost 130-138 has been identified as the Kitt Peak Wildlife Linkage and ranks as one of the 28 “highest priority” linkages of the 152 main wildlife linkages in the state due to its habitat value for mule deer, javelina, bighorn sheep, and the desert tortoise. It serves as a landscape-scale corridor among many “sky islands” along the Baboquivari Mountain range.

These particular underpasses are being constructed by “dropping in” pre-cast concrete passage structures that will provide a safe and ample corridor for wildlife to pass below SR 86. Previously, narrow box culverts served as the only means for wildlife to move under the roadway; these narrow, constrained culverts were ineffective for wildlife passage and led to wildlife trying to cross SR 86 directly and often being hit and killed in the process. The new wildlife underpasses will increase wildlife and motorist safety by reducing wildlife vehicle collisions and the existing small culverts will be removed after the new underpasses are completed.

To further strengthen and re-connect this wildlife linkage, the Tohono O’odham Nation is pursuing federal funds to design a wildlife overpass between the two underpasses to facilitate bighorn sheep movement. An additional proposal is in the works for a second overpass west of the underpasses. The Regional Transportation Authority’s Wildlife Linkages Committee, which recommended that the RTA fund construction of the two wildlife underpasses, will soon be reviewing proposals from the Nation for construction of the overpasses.

The construction of these underpasses is an accomplishment in ensuring connected ecosystems, healthy wildlife populations, and safety for both Sonoran Desert species and humans. We look forward to the completion and success of this project, and also to the construction of crossing structures on State Route 77 in the near future to preserve the Santa Catalina-Tortolita Mountain wildlife linkage! We will continue to post updates as both these projects move further along.

Click the links below to see photos and picture slideshows of the stages of underpass construction (courtesy of Norris Dodd, ADOT Environmental Services, Wildlife Connectivity Coordinator).

Completed Kitt Peak Wildlife Underpass Installation 2-27-2014

Santa Rosa Pre-Cast Arch Wildlife Underpass Slide Show

SR 86 Santa Rosa Underpass Second Phase
